Transcont WTAU-120-U0
Pt100 measuring transducer, active; fixed setting, for conversion from Pt100 to 0/4-20mA or 0-10V
- Simple commissioning due to fixed areas
- Universal power supply unit
- 3-fold galvanic isolation
Description
The Pt100 – Transmitter Transcont WTAU-120-U0 is used to create a Pt100 – Converting an electrically isolated resistance signal into a standard signal
Function
The Pt100 – Transmitter Transcont WTAU-120-U0 is designed for mounting on a standard mounting rail in accordance with DIN EN 50022 – 35.
Thanks to the integrated wide-range power supply unit for supply voltages from 20 to 253V AC and DC, the measuring transducer is suitable for use in all common international power supply networks.
Operational readiness is indicated by a green LED integrated on the front.
The Pt100 – Resistance signal is fed to the input of the transmitter and transmitted electrically isolated to the output stage.
