Rope probe SHT

Delivery Time: not specified

Well probe wired

Up to 5 electrodes possible, electrical connection via cable

  • Up to 100m rope
  • For use in drinking water
  • Corrosion-resistant


Categories: , ,


The cable electrode SHT is primarily used as a submersible sensor in conjunction with appropriate evaluation devices (eg, SRA-100-U0) for limit detection and level control in conductive liquids.

The switch point is given by the length of the connecting cable, thus a simple switching point adjustment possible. With the 2-pole version no additional mass probe is required.

The SHT-1 probe can be equipped with a cable.


SHT-2000: 2-pole, cast in one
SHT-1: 1-pole, with terminal connection

Masseelektrode_im_Kopf Korresionsbestaendig Seillaenge_100_m 4_20mA_2_PNP
Operating pressure max. pressureless
Medium temperature -20°C…+60°C
Material submersible element POM (Delrin®)
stainless steel 1.4571
Material probes stainless steel 1.4571
Isolation probe cable PVC

Documentation german

User manual

Documentation english


Product configurator
