Hydrocont® HN4

Delivery Time: not specified

Hydrostatic level transmitter / level switch with data memory for general applications – monitoring of levels in liquids – also suitable for hygienic areas

With ceramic front-flush diaphragm and TFT-display, 4-20mA or 0-10V output and up to 4 pnp switching outputs

  • Logger for up to 500’000 logs
  • Highest operation comfort due to clear text indication
  • 4x switching point and analouge output



The device is an electronic level transmitter / level switch for monitoring, control as well as continuous measurement of levels in liquids.

Due to the device construction with measuring ranges from -1 bar to 20 bar, measuring spans from 50 mbar to 20 bar, process temperatures from –40°C to +125°C and process materials Al2O3-ceramic / CrNi-steel as well as the availability of the two construction types extension cable (e.g. at limited installation situations, long sensor length) or extension tube (e.g. at strong turbulences, aggressive media, high temperatures) and the availability of industrial standard process connections like thread connection ISO 228-1 the device is especially suitable for the use for level and volume measurement, flow measurement at open channels and measuring weirs and for general applications in water and waste water sector machinery and plant engineering, air-conditioning and refrigeration plant engineering, hydraulic and pneumatic systems, process industry and environmental technology. The device is suitable for demanding measuring requirements.

Due to its high accuracy and the high flexibility of configuration, the device can be suited a wide variety of applications. The robust design and the high-quality workmanship turns the device into a very high quality product, which even the most adverse environmental conditions cannot affect, whether low temperatures when used outdoors, high shock and vibration or aggressive media.

A captive laser marking of the type label ensures the identifiability throughout the entire lifetime of the device. Obviously is the optional marking of a measurement point designation resp. TAG, a customer label or of a neutral type label, of course also per laser marking. A LABS-free resp. silicone-free version, a factory calibration with calibration certificate and a customer specific configuration resp. preset is also optionally available like a material test certificate EN10204 3.1 or factory certifications for drink water resp. food suitability.


The level measurement system Hydrocont® HN4 is built in the wall of the medium container.
The medium contacts directly the ceramic membrane of the sensor without using a pressure mediator liquid and causes there a deflection of the membrane because of the hydrostatic pressure of the medium.
At the maximum deflection the membrane contacts a robust ceramic carrier and because of this, the membrane come through over pressure of e.g. 80-times of nominal load at a sensor with a pressure range of 0…50 mbar without damage.
The fill level proportional pressure signal of the ceramic membrane is recorded from a processor with high resolution, adjusted according to the settings and converted into a high resolution output signal of 4…20mA or 0…10V.

By using optical keys and an TFT-display the sensor measurement range, the display, the PNP-switching outputs and the damping can be adjusted or the behaviour in the case of failure and the release of the fast adjustment can be set.
The switching state of the up to 4 PNP-switching output is signalled by the TFT-display.

4_20mA_4_PNP_en Bluetooth_rgb farbdisplay Bedienoberfläche Genauigkeit_0_05 Gehaese_Anzeige_drehbar
Versorgungsspannung Ausgang 0/4 bis 20 mA: 9..30 VDC, verpolungsgeschützt; Ausgang 0 bis 10 V: 14..30 VDC, verpolungsgeschützt
Stromaufnahme ≤ 50mA bis ≤ 100mA (abhängig von Ausgang, Bluetooth® ON/Off und US)
Bereitschaftszeit ≤ 1s
Sprungantwortzeit ≤ 15 ms (td = 0s / RL = 10kR)
Arbeitsbereich Analogausgang – Strom 0 bis 20mA IOut: 0 bis 20,5mA, max. 22mA;
Analogausgang – Strom 4 bis 20mA IOut: 3,8 bis 20,5mA, min. 3,6mA, max. 22mA;
Analogausgang – Spannung 0 bis 10V UOut: 0 bis 10,5 V, max. 11 V
Schaltausgang PNP S1 / S2 / S3 / S4
Funktion PNP-schaltend auf +L
Ausgangsstrom 0… ≤ 200mA strombegrenzt, kurzschlussfest
Kennlinienabweichung ≤ ±0,05% / ±0,1% / ±0,2% FS
Langzeitdrift ≤ ± 0,1% FS / Jahr nicht kumulativ
Temperaturabweichung Nullpunkt: ≤ ±0,015% FS / K, max. ±0,75 % (-20°C bis +80°C);
Spanne: ≤ ±0,015% FS / K, max. ±0,5 % (-20°C bis +80°C / > 0,4 bar), max. ±0,8 % (-20°C bis +80°C / ≤ 0,4 bar)
Membrane (mediumberührend) Prozessanschluss – Typ 7 – G1½“ / Sensor Ø40mm: Keramik Al2O3 – 99,9%;
Prozessanschluss – Typ 8 – G¾“ / Sensor Ø22mm Messbereich ≤ 1bar: Keramik Al2O3 – 99,7%;
Prozessanschluss – Typ 8 – G¾“ / Sensor Ø22mm Messbereich ≥ 1,6bar: Keramik Al2O3 – 96%
Prozessanschluss (mediumberührend) Stahl 1.4404/316L / Stahl 1.4571/316Ti
Anschlussgehäuse CrNi-Stahl
Dichtungen (mediumberührend) FPM – Fluorelastomer (z.B. Viton®);
EPDM – Ethylen-Propylen-Dienmonomer, FDA-gelistet;
FFKM – Perfluorelastomer (z.B. Kalrez®);
FFKM hd – Perfluorelastomer hochdicht
Umgebungstemperatur -20°C bis +70°C
Prozesstemperaturen -40°C bis +100°C (Erweitert -40°C bis +125°C)
Prozessdruckbereiche -1bar bis 20bar (abhängig von Prozessanschluss)
Schutzart IP65/IP67
EN/IEC 60529
