Silocont SIC-350
Rotary paddle switch Silocont SIC-350
- Robust and cost efficient
- For all kinds of bulks
- ATEX-approval
Description
The economical Solicont SIC-350 is a paddle switch for point level detection in bulk materials. Its robust polymer housing and compact design makes it an ideal sensor for full, empty and demand alarm in applications with bulk solids. The optimized polymers make the unit outstandingly robust and therefore suitable for use in dust explosive areas according the latest standards.
Field of application
Process connections: NPT 1½”, PBT; NPT 1¼”, PBT; G 1½”, PBT; NPT 1½”, 1.4305; NPT 1¼”, 1.4305; G 1½”, 1.4305
Sensor length: Different standard lenghts between 100mm (4″) and 600mm (24″), additional rope length of 2000 mm (80″) (can be shortened)
Medium temperature: -20 to +80°C (-4 to +170°F)
Pressure: 0.5 to 1.8bar (7 to 25psi)
ATEX II 1/3 D, CSA DIP/ II, III/1/E-G, FM DIP/ II, III/1/E-G
| Measuring Principle | Paddle |
|---|---|
| Characteristic / Application | Universally applicable as a full, empty and demand alarm on silos containing solids |
| Supply / Communication | 230 VAC 50/60Hz 115 VAC 50/60Hz 24 VAC 50/60Hz 20 V bis 28 V DC |
| Ambient temperature | -20°C…+60°C |
| Process temperature | -20°C…+80°C |
| Process pressure absolute | 0,5bar bis 2,5bar |
| max. overpressure limit | ≤ 1,5bar |
| Min. density of medium | ≥ 80 g/l |
| Main wetted parts | 1.4305 |
| Max. tensile strength | Rope version > 1500N |
| Process connection | NPT 1½”, PBT NPT 1¼”, PBT G 1½”, PBT NPT 1½”, 1.4305 NPT 1¼”, 1.4305 G 1½”, 1.4305 |
| Sensor length | 75mm 100mm 120mm 200mm 300mm Rope length of approx. 2000mm, can be shortened |
| Output | Micro switch with changeover contact max. 6A / 250 VAC 100mA |
| Certificates / Approvals | ATEX II 1/3 D CSA DIP/ II CSA DIP/ III/1/E-G (requested!) FM DIP/ II FM DIP/ III/1/E-G |
| Options | Rotation Monitoring System Signal Lamp Fold-away paddle Weather protection cover |
| Specialities | Rotation Monitoring System Fold-away paddle |
