Ultrasonic sensor Sonicont USP4

Delivery Time: approx. 3-4 workdays

Ultrasonic sensor for non-contact level measurement in liquids and bulk solids

  • Easy to operate via Bluetooth® and App
  • Slender design
  • Combinable with measuring tube, this avoids adjustment



Description

The ultrasonic sensor Sonicont USP4 is an ultrasonic sensor for non-contact level measurement and monitoring in liquids and bulk solids. The sensor is designed as a suspension version with a cable outlet or as a screw-in sensor with a cable or plug connection. Thanks to its slim design, the sensor can be inserted through small container bores or installed in thin monitoring wells.
The ultrasonic sensor Sonicont USP4 can optionally be combined with measuring tubes made of PE. This gives the ultrasonic signal a defined measuring path, which means that there are no influences that would affect the ultrasonic signal, for example, from oxidized and uneven level pipes or container walls.
The electronics are designed as a 4… 20mA 2-wire signal. In order to ensure safe operation, especially outdoors, the Sonicont USP4 has integrated surge protection.
Due to its high accuracy, the compact sensor can be used for a wide variety of applications in the field of groundwater and surface water measurements, tank monitoring, wastewater and distance measurements. Using a free app, the Sonicont USP4 can be adapted to the respective operating conditions via Bluetooth® 5.0 LE.

Application

  • Non-contact level and volume measurement
  • Flow measurement at open channels and measuring weirs
  • Water and waste water sector
  • Process industry
  • Environmental technology
  • Storage tanks, storage bunkers, silos

Advantages

  • Measuring ranges up to 8m
  • Connector plug M12 or extension cable version
  • High protection class IP65 / IP67 resp. IP68
  • Process temperature range –20°C to +70°C
  • Electronic 4…20mA in 2-wire-technology
  • High accuracy ≤ 0,2%
  • Operating interface Bluetooth® 5.0 LE
  • Integrated overvoltage protection
  • Envelope curve indication
  • Temperature compensation and interference echo suppression
Schuettgueter_Fluessigkeiten beruehrungslose_Messung Bauform_schlank Bluetooth_rgb Ueberspannungsschutz Temperaturmessung_integriert
Eingang Distanz
Messbereich 0m…2m (bei Variante Messbereich 02)
0m…5m (bei Variante Messbereich 05)
0m…8m (bei Variante Messbereich 08)
Blockdistanz BD ≤ 0,10m (typ. 0,06m)
≤ 0,15m (typ. 0,10m)
≤ 0,30m (typ. 0,19m)
Pulsrate tp
(Messzykluszeit)
≤ 10Hz / ≥ 100ms
≤ 4Hz / ≥ 250ms
≤ 2Hz / ≥ 500ms
Kennlinienabweichung ≤ ±2mm oder ±0,2%FSO
Temperaturabweichung Tk Nullpunkt (Mittelwert) ≤ ±0,006% FSO/K
Ausgang Strom 4…20mA Bluetooth® 5.0 LE
Analogausgang 4…20mA 3,8mA…20,5mA
≥ 3,6mA
≤ 22mA
dI ≤ 1µA
Zeitverhalten T90 ≤ Pulsrate tp (td = 0s)
ton ≤ 3s (td = 0s)
Schnittstelle Bluetooth® 5.0 LE (2Mbit/s)
Hilfsenergie
Versorgungsspannung Us
(verpolungsgeschützt)
11 V…35 V DC
Überspannungsschutz
Grobschutz 75 V /10kA – Welle 8/20µs / +L/-L gegen Kabelschirm (bei Elektrischer Anschluss Variante K/H/O)
150 V / 10kA – Welle 8/20µs / +L gegen -L
Feinschutz 36V
Alle Leitungen gegen / +L gegen -L
Umgebungsbedingungen
Umgebungstemperatur -20°C…+70°C
Schutzart IP68 [≤ 3m/≤ 0,3 bar] (EN/IEC 60529) (bei Elektrischer Anschluss Variante K/H/O)
IP65/IP67 (EN/IEC 60529) (bei Elektrischer Anschluss Variante S)
Werkstoffe
(prozessberührend)
PVDF
POM
PA
NBR
FPM
PE
PUR
